FoxIDs is an open source identity service supporting login, OAuth 2.0, OpenID Connect 1.0 and SAML 2.0.
FoxIDs can at the same time work as both an authentication platform and a security broker converting between standards.

STATUS: I'm currently working on the documentation and the first FoxIDs release.

FoxIDs consist of two services:

  • Identity service called FoxIDs which handles user login and all other security traffic.
  • Configuration client and API called FoxIDs Control. The FoxIDs Control Client is used to configure FoxIDs, or alternatively by calling the FoxIDs Control API directly.

Deployment or as a service:

  • FoxIDs is a cloud service ready to be deployed in you Azure tenant.
  • Or you can use FoxIDs as an identity as a service (IDaaS) at FoxIDs.com.

FoxIDs is .NET 5.0 and the FoxIDs Control Client is Blazor .NET Standard 2.1.

Free and Open Source

FoxIDs is free and the open source with a GitHub repository.
The license grant all (individuals, companies etc.) the right to use FoxIDs for free. The license restricts reselling FoxIDs e.g. as a cloud service to third parties, without a supplementary agreement.

Support

Please ask your question on Stack Overflow and email a link to [email protected] for me to answer.

How FoxIDs works

FoxIDs is a multi-tenant system designed to be deployed in the Azure cloud. FoxIDs support being deployed as a service used by many companies, organizations etc. each with its one tenant. Or to be deployed in a company's Azure subscription where only one tenant is configured in FoxIDs holding the company's entire security service.

FoxIDs is deployed in two App Services which expose:

  • FoxIDs, the identity service which handles all the security requests and user authentication
  • FoxIDs Control, the administration application and API in which FoxIDs is configured

Both is exposed as websites where the domains can be customized. FoxIDs also relay on a number of backend service, please see development for details.

Structure

FoxIDs is divided into logical elements.

  • Tenant contain the company, organization, individual etc. security service. A tenant contains the tracks.
  • Track is a production, QA, test etc. environment. Each track contains a user repository, a unique certificate and a track contains the up parties and down parties.
  • Up-party is a upwards trust / federation or login configuration. Currently support: login (one view with both username and password) and SAML 2.0. Future support: OpenID Connect and two step login (two views separating the username and password input).
  • Down-party is a downward application configuration. Currently support: OpenID Connect (secret or PKCE), OAuth 2.0 API and SAML 2.0.

FoxIDs structure

FoxIDs support unlimited tenants. Unlimited tracks in a tenant. Unlimited users, up parties and down parties in a track.

Separation

The structure is used to separate the different tenants, tracks and parties.

If the FoxIDs is hosted on https://foxidsxxxx.com/ the tenants are separated in the first folder of the URL https://foxidsxxxx.com/tenant-x/. The tracks are separated in the second folder of the URL https://foxidsxxxx.com/tenant-x/track-y/ under each tenant.

A down-party is call by adding the down-party name as the third folder in the URL https://foxidsxxxx.com/tenant-x/track-y/down-party-z/.
A up-party is call by adding the up-party name insight round brackets as the third folder in the URL https://foxidsxxxx.com/tenant-x/track-y/(up-party-v)/. If FoxIDs handles a up-party sequence like e.g. user authentication the same URL notation is used thus locking the session cookie to the URL.

A client (application) starting an OAuth 2.0, OpenID Connect or SAML 2.0 login sequence would like to specify in which up-party the user should authenticate. The resulting up-party is specified by adding the up-party name in round brackets in the URL after the down-party name https://foxidsxxxx.com/tenant-x/track-y/down-party-z(up-party-v)/.

The allowed up parties for a down-party is configured for each down-party in FoxIDs Control.

Selecting multiple up parties (future support):

  • Select all up parties allowed for a down-party by adding a star in round brackets in the URL after the down-party name https://foxidsxxxx.com/tenant-x/track-y/down-party-z(*)/
  • Select a maximum of 5 up parties allowed for a down-party by adding the up parties as a comma separated list in round brackets in the URL after the down-party name https://foxidsxxxx.com/*tenant-x*/*track-y*/*down-party-z*(up-party-v1*,up-party-v2*,up-party-v3,up-party-v4,up-party-v5)/

A client which use client credentials as authorization grant would not specify the up-party. It is likewise optional to specify the up-party when calling an OpenID Connect discovery document or a SAML 2.0 metadata endpoint.

Certificates

When a track is created it is default equipped with a self-signed certificate stored in Cosmos DB, called a contained certificate. The certificate can afterword's be updated / changed and likewise the certificate container type can be changed.

There are tree different certificate container types:

Contained certificates (default)

  • Certificates is stored in Cosmos DB including private key.
  • Self-signed certificates is created by FoxIDs or you can upload your one certificates.
  • Support primary and secondary certificates, and certificate swap.
  • Not automatically renewed.
  • No cost per signing.

Key Vault, renewed self-signed certificates

  • Certificates is stored in Key Vault and the private key is not exportable.
  • Self-signed certificates is created by Key Vault.
  • Automatically renewed with 3 month validity period. Renewed 10 days before expiration and exposed as the secondary certificate. Promoted to be the primary certificate 5 days before expiration.
  • Key Vault cost per signing.

Key Vault, upload your one certificate (future support)

  • Certificates is stored in Key Vault and the private key is not exportable.
  • Not automatically renewed.
  • Key Vault cost per signing.
